FF300R12KE4PHOSA1
TQIN Code
TQ-FF300R12KE4PHOSA1
Manufacturer
Infineon Technologies
Mfr Part #
FF300R12KE4PHOSA1
Detailed Description
IGBT Module Trench Field Stop Half Bridge Inverter 1200 V 300 A Chassis Mount Module
DataSheet
Product Attributes
TYPE | DESCRIPTION |
|---|
Product Status | Active |
Package | Tray |
Package / Case | Module |
Mounting Type | Chassis Mount |
Voltage - Collector Emitter Breakdown (Max) | 1200 V |
IGBT Type | Trench Field Stop |
Supplier Device Package | Module |
Operating Temperature | -40°C ~ 150°C |
Input Capacitance (Cies) @ Vce | 19 nF @ 25 V |
Input | Standard |
NTC Thermistor | No |
Series | C |
Configuration | Half Bridge Inverter |
Current - Collector (Ic) (Max) | 300 A |
Current - Collector Cutoff (Max) | 5 mA |
Vce(on) (Max) @ Vge Ic | 2．15V @ 15V 300A |
Base Product Number | FF300R12 |
RoHS Status | ROHS3 Compliant |
Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
REACH Status | REACH Unaffected |
ECCN | EAR99 |
HTSUS | 8541.29.0095 |
Standard Package | 8 |
In Stock：
0
